Images

Bill of Materials

This should all be iuncluded in the macropad kit.

5x Cherry MX Switches

1x Alps EC11E Rotary Encoder

1x Seeeduino XIAO

1x 0.91" 128x32 OLED Display

4x M3 screws

Notes

This is my first hardware project and I hope It turns out well... waiting for a review and working on minor improvements in the meantime.
